Type of Protective Board	3S lithium battery protection board
Battery Type	Li-ion
Compatible Interface	SMBUS
Over charge detection voltage(Cell)	4.230V±0.025V
Over Discharge Detection Voltage(Cell)	2.700V±0.025V
Over Current Discharge	5A±0.5A
Over Current Charge	4A±0.5A
Discharging Temperature	0~50 ℃
Charging Temperature	-20~60 ℃
Max. Discharge Current	5A
Max. charge Current	5A
Dimensions	53.9*18.51*1.0mm
Design Certification Requirements	Conform to UL2054、IEC62133、KC、PSE

High-Discharge, Controlled-Charge Power Management for 1S Battery Systems

The BAKTH-ITL0030050162-01 is a precision-engineered 3-series (3S) Battery Management System (BMS) designed for 11.1V lithium-ion and lithium-polymer battery packs. Featuring an slim form factor of just 53.9mm × 18.51mm × 1.0mm and symmetrical 5A maximum continuous charge and discharge current, this protection board delivers exceptional power management in an incredibly compact package. Its narrow, low-profile design makes it the ideal solution for space-constrained applications such as slim power tools, compact drones, and portable electronics where every millimeter of space matters.

This BMS integrates comprehensive protection features with precision cell balancing, ensuring optimal battery health, safety, and consistent performance throughout its service life. The ultra-thin 1.0mm profile allows for integration into devices where traditional thicker boards simply cannot fit.



Key Features & Benefits:

• Comprehensive Protection:

  • Over-charge protection

  • Over-discharge protection

  • Over-current protection

  • Short-circuit and temperature protection

• Precision Balancing: Equipped with passive balancing functionality

• Compact Design: Space-optimized layout for easy integration into various battery packs

Power your high-performance applications with confidence. Contact us for volume pricing and detailed technical data sheets！
