Type of Protective Board	1S lithium battery protection board
Battery Type	Li-ion
Compatible Interface	I2C
Over charge detection voltage(Cell)	4.280V±0.030V
Over Discharge Detection Voltage(Cell)	2.800V±0.050V
Over Current Discharge	10A-20A
Over Current Charge	10A-20A
Discharging Temperature	0~50 ℃
Charging Temperature	0~60 ℃
Max. Discharge Current	5A
Max. charge Current	5A
Dimensions	Φ18.3*0.6mm
Design Certification Requirements	Conform to UL2054、IEC62133、KC、PSE

High-Discharge, Controlled-Charge Power Management for 1S Battery Systems

The BAKTH-ITL0010030165-01 is a precision-engineered 1-series (1S) Battery Management System (BMS) designed specifically for 3.7V lithium-ion and lithium-polymer battery packs. Featuring an ultra-thin circular form factor (Φ18.3mm × 0.6mm) and symmetrical 5A maximum continuous charge/discharge current, this protection board delivers robust power management in an exceptionally compact package. Its unique circular design and minimal thickness make it the ideal solution for space-constrained applications such as smart wearables, compact IoT devices, and miniaturized electronics where every millimeter counts.

This BMS integrates comprehensive protection features with ultra-low power consumption, ensuring optimal battery safety, longevity, and performance in the most demanding compact device designs.



Key Features & Benefits:

• Comprehensive Protection:

  • Over-charge protection

  • Over-discharge protection

  • Over-current protection

  • Short-circuit and temperature protection

• Precision Balancing: Equipped with passive balancing functionality

• Compact Design: Space-optimized layout for easy integration into various battery packs

Power your high-performance applications with confidence. Contact us for volume pricing and detailed technical data sheets！
