Type of Protective Board	10S lithium battery protection board
Battery Type	Li-ion
Over charge detection voltage(Cell)	4.250V±0.050V
Over Discharge Detection Voltage(Cell)	2.500V±0.050V
Over Current Discharge	50±10A
Over Current Charge	50±10A
Discharging Temperature	0~55 ℃
Charging Temperature	0~65 ℃
Max. Discharge Current	20A
Max. charge Current	20A
Dimensions	125*60*1.6mm
Design Certification Requirements	Conform to UL2054、IEC62133、KC、PSE

High-Discharge, Controlled-Charge Power Management for 10S Battery Systems

This protection board (BMS) is specifically designed for 10-series (10S) lithium-ion battery packs, supporting a continuous charge/discharge current of 20A. It is suitable for 36V (nominal) or 42V (full charge) battery systems. Model number: BAKTH-ITL0100100159-01.



Key Features & Benefits:

• Comprehensive Protection:

  • Over-charge protection

  • Over-discharge protection

  • Over-current protection

  • Short-circuit and temperature protection

• Precision Balancing: Equipped with passive balancing functionality

• Compact Design: Space-optimized layout for easy integration into various battery packs

Power your high-performance applications with confidence. Contact us for volume pricing and detailed technical data sheets！
