Technical Specifications:

• Chemistry: Li-pol

• Nominal Voltage: 3.7V

• Nominal Capacity: 5300mAh

• Nominal Energy: 19.61Wh

• Max Charge Voltage: 4.2V

• Discharge cut off voltage: 2.8V

• Discharging temperature: -20~60℃

• Dimension: about 7.2 × 46× 148 mm

• Weight: about 95g



The BAKTH-7045145H-1S-3 is a high-capacity, ultra‑slim lithium polymer battery pack designed for applications that need long runtime without bulky thickness. With a 5300mAh (19.6Wh) capacity and a sleek 7.2mm profile, this single‑cell (1S) pack delivers stable 3.7V nominal voltage and integrates easily. Its large yet thin format (148mm × 46mm × 7.2mm) makes it an excellent power source for portable TVs, tablet computers, medical carts, portable monitors, high‑capacity power banks, and other space‑sensitive devices.



Key Features & Benefits

• Massive 5300mAh Capacity – 19.6Wh Energy
  Provides extended runtime for power‑hungry portables – enough for hours of video playback, all‑day operation of medical carts, or multiple charges for smartphones in a power bank.

• Ultra‑Slim 7.2mm Profile
  Despite its high capacity, the pack measures only 7.2mm thick, fitting easily into slim product enclosures. The large surface area (148×46mm) spreads the thickness for better heat dissipation.

• Grade‑A Li‑Polymer Pouch Cells
  Manufactured with high‑energy‑density lithium polymer cells, offering low internal resistance, flat discharge voltage.

• Stable Voltage & Safe Operation
  Integrated protection circuit (PCM) guards against over‑charge, over‑discharge, and short circuits. Designed for use with standard 4.2V Li‑ion charging systems.

Order Now and power your innovations with a trusted energy solution!



About US:

Shenzhen BAKTH Technology Co., Ltd. was established in 2002. For 21 years, it has been dedicated to battery pack assembly and PCM/BMS design and production. It has a 5,000-square-meter self-owned factory equipped with automated production lines and SMT assembly lines.

•
•
• Certificates:
•
•
• FAQ:
• 1. What kind of certificate your battery pack owned?
  Re: ISO9001, ISO14001, UL, BIS, KC, USTC, CE, CB, our battery pack have reliable quality assurance.

  2. Do you have MOQ?
  Re: No limitation, we will check the best price for you based on your order quantity. We warmly welcome sample order to test our quality before bulk order.

  3. What’s the warranty? How can we guarantee quality?
  Re: Normally will be 12 months, for some special products can be further negotiated accordingly. A complete production process to ensure the quality before shipment.

• 4. What’s the lead time?
  Re: Standard products: sample order will be 3~4 weeks based on the battery cell in stock, 5~8 weeks for bulk order according to different models and quantity.

  5. Can we have our own Logo on the battery pack? Can you accept customized battery?
  Re: Yes, of course. BAKTH Technology has professional R&D team which could provide you the most suitable solution according to your requirements. Customized battery requirements are warmly welcomed!
